Honeycomb Paper Making Machine

Honeycomb Paper Making Machine

1. This machine is suitable for die cutting honeycomb paper,wrapping paper, shock-absorbing paper, kraft paper,fish net paper from 70g to 100g.
2. The unwinding,cutting and rewinding in one process.
3. Main motor equipped with Inverter for speed regulation.
4. Automatic ultrasonic web guide controller for unwinding.
5. Tension controlled by magnetic powder brake and clutch.
6. Automatic meter counting device,automatically stop after it reaches the length you set.
7. Pneumatic cylinder to control the cutting mould up and down.
8. Roll to sheet cutting is optional.(can match our paper wrapper)
Online Inquiry Contact Us

Product Details

Application

Honeycomb paper is eco-friendly and cost effective alternative for plastic bubble wrap cushioning.It is easy to stretch,more soft and flexible,provide cushion protect without surface scratch.Finished products from this machine can be used to pack fruits,flowers，ceramics,glassware,etc.

Technical parameters:

Machine model

SD-PH600

Max material width

515mm (508mm/20inch and 380mm/15inch width most)

Machine working speed

0-200m/min adjustable

Unwinding diameter

0-1200mm

Rewinding diameter

0-300mm

Unwinding roll weight

Max. 1 Ton

Unwinding shaft

3”inflatable air shaft

Rewinding shaft

1”/1.5”/2”/3” air shaft (choose either one,usually is 1.5”)

Machine size

2600*1350*1300mm(LxWxH)

Machine weight

1500KG

Power supply

380V 3 Phase or as customer requirement
