Technical parameters:
|
Machine model |
SD-PC700 |
|
Paper thickness |
50～70g |
|
Feeding box |
30-50pcs cores feeding/group |
|
Paper core height |
10-15mm |
|
Paper core width |
80-160 layers (10-20mm) |
|
Paper core length |
200-700mm (220mm,350mm,450mm most common),if do 220mm,can be 3 cores feeding by one time,if 350mm,can be 2 cores feeding by one time |
|
Machine working speed |
4pcs-12pcs/min(if finished length is 220mm,can do 3pcs by one time,so speed is 12pcs/min) |
|
Glue type |
Water based glue |
|
Computer Control |
Servo motor,touch screen and PLC control |
|
Power |
3KW |
|
Air pressure |
0.6mpa |
|
Machine size |
1500*750*1300mm (LxWxH) |
|
Machine weight |
500 KG |
