Technical parameters:
|
Machine model |
SD-PF500A |
|
Max material width |
470mm |
|
Machine working speed |
90m/min |
|
Unwinding diameter |
0-1200mm |
|
Stacking system |
By conveyor |
|
Unwinding stand weight |
1 Ton |
|
Unwinding shaft |
3” inflatable air shaft |
|
Machine size |
2800*1200*1300mm(LxWxH) |
|
Machine weight |
800KG |
|
Power supply |
380V 3 Phase |
This paper folding machine is a new design with two roll Kraft paper feeding and do C type folding inline to form one 2-layer paper and then do perforation cutting and folding finally. The finished paper will be in fanfold type and has much stronger in surface as packing cushioning material.
This Fanfold Kraft Paper Perforated Cutting and Folding Machine is our newest design for making the kraft paper roll for paperEZ,Ranpak company.The kraft paper roll get perforated cutting and folding by ourmachine automatically and stack to a pile to be collected.
